Coibhéiseach le:

● AESSEAL M01S

● VULCAN 1609S

● JOHN CRANE 8-1

● STERLING 290S

Teorainneacha Oibriúcháin:

● Teocht: -40 céim - móide 260 céim

● Brú: Níos lú ná nó cothrom le 24bar

● Luas: Níos lú ná nó cothrom le 25m/s

● Méid na Seafta: 0.5" - 6"

Ábhair:

● Fáinní Séala: Carbón Roisín, Carbón Antamón, SIC, SSIC, Carbide Tungstain

● Leaistiméire: VITON, EPDM, NBR, FFKM, AFLAS

● Cuid Miotail: SS304, SS316, Duplex, Hastelloy C

Tionól Dwg:

Toisí (mm):

Méid(orlach)	D	D3	D4	D6	D7	L1	L3
0.500	12.70	26.70	30.00	14.5	25.60	21	7.90
0.625	15.87	30.70	34.00	17.5	31.95	19	10.30
0.750	19.05	34.00	37.00	21	35.12	22.2	10.30
0.875	22.22	37.20	40.00	24	38.30	24	10.30
1.000	25.40	40.30	43.00	27.5	41.48	25	11.15
1.125	28.57	43.50	46.00	30.5	44.65	27	11.15
1.250	31.75	48.30	51.00	33.5	47.83	27	11.15
1.375	34.92	51.50	54.00	37	51.00	29	11.15
1.500	38.10	54.60	58.00	40	54.18	29	11.15
1.625	41.27	61.00	64.00	43.5	60.53	35	12.75
1.750	44.45	64.20	67.00	46.5	63.70	35	12.75
1.875	47.62	67.30	70.00	49.5	66.88	35	12.75
2.000	50.80	70.50	73.00	53	70.05	35	12.75
2.125	53.97	76.90	80.00	56	76.40	43	14.33
2.250	57.15	80.00	83.00	59	79.58	43	14.33
2.375	60.32	83.20	86.00	62.5	82.75	43	14.33
2.500	63.50	86.40	89.00	65.5	85.93	43	14.33
2.625	66.67	89.60	92.00	68.5	85.93	43	15.93
2.750	69.85	92.70	96.00	72	89.10	43	15.93
2.875	73.02	95.90	99.00	75	95.45	43	15.93
3.000	76.20	97.50	100.00	78.5	98.63	43	15.93
3.125	79.37	100.70	104.00	81.5	101.80	43	19.84
3.250	82.55	105.40	108.00	84.5	104.98	43	19.84
3.375	85.73	108.60	111.00	88	108.15	43	19.84
3.500	88.90	111.80	115.00	91	111.13	43	19.84
3.625	92.08	115.00	118.00	94	114.35	43	19.84
3.750	95.25	118.10	121.00	97.5	117.68	43	19.84
3.875	98.43	121.30	124.00	100.5	120.85	43	19.84
4.000	101.60	124.50	127.00	103.5	124.03	43	19.84
4.125	104.78	130.20	134.00	107	130.38	42.9	19.84
4.250	107.65	133.40	137.00	110	133.55	42.9	19.84
4.375	111.13	136.50	140.00	113.5	136.72	42.9	19.84
4.500	114.30	139.70	143.00	116.5	139.90	42.9	19.84
4.625	117.48	142.90	146.00	119.5	143.08	42.9	19.84
4.750	120.65	146.10	146.00	122.5	146.25	42.9	19.84
4.875	123.83	149.20	153.00	126	149.43	42.9	19.84
5.000	127.00	152.40	156.00	129	152.60	42.9	19.84
5.125	130.18	155.60	159.00	132	155.77	42.9	19.84
5.250	133.35	165.10	168.00	135.5	158.95	50.8	19.84
5.375	136.53	168.28	171.45	138.5	162.12	50.8	19.84
5.500	139.70	171.50	175.00	141.5	165.30	50.8	19.84
5.625	142.88	174.60	178.00	145	168.47	50.8	19.84
5.750	146.05	177.80	181.00	149	177.23	50.8	25.40
5.875	149.23	181.00	14.00	152.5	180.41	50.8	25.40
6.000	152.40	184.20	188.00	155.5	183.59	50.8	25.40

Réamhrá Gaolmhara

Bunriachtanais ábhair róin mheicniúla:

① An bhfuil airíonna meicniúla áirithe, mar shampla neart teanntachta, fadú, etc.;

② Tá an elasticity agus cruas oiriúnach, agus tá an dífhoirmiúchán buan comhbhrúite beag;

③ Tá sé resistant do theocht ard agus íseal, ní dhianscaoileann sé nó a laghdaíonn ag teocht ard, agus ní chruann sé ag teocht íseal;

④ Ag luí leis an meán oibre, gan swelling, lobhadh, hardening, etc.;

⑤ Friotaíocht ocsaídiúcháin maith agus friotaíocht ag dul in aois, durable;

⑥ Caith-resistant agus neamh-chreimneach do mhiotail;

⑦ Éasca le foirmiú agus próiseáil, agus praghas íseal.
